380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending

    Buy cheap 380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending from wholesalers

    Buy cheap 380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending from wholesalers
    • Buy cheap 380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending from wholesalers
    • Buy cheap 380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending from wholesalers
    • Buy cheap 380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending from wholesalers

    380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending

    Ask Lasest Price
    Brand Name : Qifu
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 10,000 units per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    380V/220V Automatic Steel Bending Machine DIA 4-8mm Steel Wire Bending

    Simple and safe operation DIA 4-8mm steel wire bending machine steel bending machine,


    Description:


    Rebar bending machine, one of the rebar processing machinery. The working mechanism is a horizontal working plate that rotates on a vertical axis. The steel bar is placed at the dotted line in the figure, the support pin is fixed on the machine tool, the center pin and the bending pin are installed on the working plate, when the steel bar is bent, the disc rotates. In order to bend steel bars of various diameters, there are several holes on the working plate for inserting and pressing the bending pins, and the center pins of different diameters can be replaced accordingly.


    Advantage:


    It can bend the diameter of the steel rod into any desired shape and is suitable for bridges, tunnels and many construction projects.
    1. Low labor intensity and high work efficiency.
    2. One time programming, can bend 1-10 angles, and can also automatically switch all the angles set by the program.
    3. The angle can be adjusted arbitrarily (1-350 degrees), the angle is accurate, and the tolerance is less than ±1.
    4. Single-foot pedal, one-key operation, simple and quick operation, saving time and effort.
    5. The starting point control accuracy, the tolerance of the large spring frame is less than ±0.5.


    Why choose us:


    1. Excellent quality, user-friendly design, factory direct price, professional after-sales service.
    2. Best-selling in North America, Europe, Africa and other parts of the world.
    3. Industry with relevant work experience in construction machinery


    product nameSteel bending machine
    OriginChongqing, China
    Coloras shown
    Voltage380V/220V
    Power1500W
    Bending speed3-5s
    Bending angle​0-180 degrees
    ​Bending diameterGrade 3 ribbed steel bar 6-40mm
    Applicable industriesenergy and mining, machinery repair shops, manufacturing plants, construction engineering, building materials stores
