    ISO Roll Thread Machine Automatic Construction Works Rebar Screw

    Ask Lasest Price
    Brand Name : Qifu
    Model Number : HGS40, HGS40DZ, HGS40KZS, HGS40DZS, HGS50
    Certification : ISO
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 10,000 units per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    ISO Roll Thread Machine Automatic Construction Works Rebar Screw

    Factory Best Price Rebar Rolling Machine Automatic Construction Works Rebar Screw


    Product Description

    Steel bar thread rolling machine is mainly used for rolling straight threaded head of ribbed steel bar in construction engineering. It is the key equipment for realizing straight threaded connection of reinforced steel bar.
    The steel bar rolling thread connection technology is suitable for industrial and civil buildings. Its process is simple and fast, no open flame operation, no pollution to the environment, no explosion fire hazards, safe and reliable, and can be constructed around the clock, saving a lot of steel and energy.
    Only a spanner is used to connect the steel bars, and each steel bar joint is about one minute, which shortens the construction period and realizes industrialized and civilized construction.
    HGS Series Rebar Thread Rolling Machine:

    Machine Main Features


    1. Rib stripping and rolling thread can be processed in one clamping.Full processing tooth shape, high dimensional accuracy.
    2. Machinable positive and negative thread.
    3. The machine is simple to operate, compact in structure, reliable in operation, and has a unique automatic cutter opening and closing mechanism.
    4. The strength of the wire head is higher than the strength of the base material without cutting the base material of the reinforcing bar.
    5. Wide application range, can process ribbed steel bars with diameter of 16 - 40.


    After-sales Service:Online Technical Support, Onsite Installation, Ons
    Warranty:1-year
    Suitable for:Aluminum, Alloy, Stainless Steel
    Custom:Customized Graphic, Logo and Packing Are Available
    Transport Package:Customized

    Rebar thread diameter:16-40mm
    Motor power:4kw
    Voltage:3-380V 50Hz
    Thread rolling speed:40-62 rpm
    Maximum thread length:80mm
    Thread angle:60°, 75°
    Work efficiency:30-40mm/min
    Weight:450 kg

    Features

    1.It can complete rib peeling and rebar thread machine one time.

    2.Good shape of thread and high precision.

    3.Right thread and left thread are all available.

    4.Left-handed and Right-handed thread can be processed.

    5.Simple operation, good quality,realiable working,and high efficiency.


    Basic Info.

    Model NO.
    Rebar Thread Rolling Machines
    Warranty
    Within 1 Year
    Model Number
    HGS40, HGS50
    Speed
    62rpm /40-62rpm
    Material
    Metal
    Transport Package
    Wooden Case or Iron Frame, 1 Set /Package
    Specification
    ISO9001
    Trademark
    rebar thread rolling Machine
    Origin
    Chongqing China
    HS Code
    8459700000

    ISO Roll Thread Machine Automatic Construction Works Rebar ScrewISO Roll Thread Machine Automatic Construction Works Rebar Screw


    Our Services

    Before sales: Engineering Consultance Service & Technical Support

    After sales : Process clients' feedback and or problems during the operation of the

    equipments/machines within 24 hours.

    OEM service: We accept OEM orders and 70 percent of our clients are enjoying OEM services.
